The vision of ArduSimple is to make GNSS RTK technology simple, affordable and accessible to everyone with a series of starter kits, tutorials, engineering services and OEM products.
Shield for C099-F9P
SKU: AS-ADP-C099-TO-XBEEHP-00
49,00€
Availability: In stock
This product comes with 2 years worldwide warranty
This product has quantity discounts available:
| Units | Price per unit |
|---|---|
| <50 | 49,00€ |
| >=50 | Contact us for special pricing |
| >500 | Contact us for special pricing |
Includes:
– 1x Shield for C099-F9P
With the ArduSimple Shield for C099-F9P you will be able to add any ArduSimple plugin to your u-blox C099-F9P board. Make sure the switch is moved towards “XBEE TO C099”.
The Shield is connecting the UART TX/RX of the XBee device mounted on it, to the J9 connector of C099-F9P, pins 1 (RXD_ZED_ARD) and 2 (TXD ZED). This means:
- The RX of the Shield goes to ZED-F9P TX1.
- The TX of the Shield goes to a multiplexer, which can be connected directly to ZED-F9P RX1.
Documentation
Start here:
Datasheet- We didn't find time to create this 3D CAD model, contact us to request it
